Molecular Deionized/Demineralized Water System

The small, portable reverse osmosis water purification machine is designed for providing deionized water. It is easy to install and user-friendly, making it convenient for users to operate. Equipped with 4 wheels, the machine is easily movable for added convenience.

Package Includes:

1. Molecular Pure Water Machine - 150L/H
• Model: Molro 2150d - 1 set

One Year Consumable Filters:

1. 1st Stage 5μm PP Filter
• Model: Molcot20- 9 pcs
2. 2nd Stage Activated Carbon Filter
• Model: Molgac20- 6 pcs
3. 3rd Stage 1μm PP Filter
• Model: Molpp20- 6 pcs
4. RO Membrane
• Model: molrofilm 300G -12 pcs

Technical Parameters
Model: Molro 2150d (Double Pass RO)
Dimensions: L850 * W1250 * H1500 mm

Main Technical Parameters:

1. Power Supply: 220V/50Hz, 1400W
2. Operating Temperature: 5-40°C
3. Humidity Range: 10%-80%

Feed Water Quality Requirements:

• Input Water TDS: < 300 ppm
• Turbidity: Less than 25 NTU
• pH: 6 to 8
• Total Hardness: Less than 70 mg/L
• Chloride Content: Less than 7 mg/L
• Water Temperature: 5-40°C
• Input Water Pressure: 0.15-0.3 Mpa
• Feed water require 0.15－0.30Mpa (if above 0.30 Mpa, then the customer needs to take decompression measures, otherwise, it is easy to overpressure to cause damage leakage; if below 0.10 Mpa, the alarm will be triggered and the machine stops working, then the feed water pump is needed)

Pure Water/Output Water/Production Water Quality (One Type):

• Pure Water Conductivity: < 15 μS/cm @ 25°C
• Conforms to China National Laboratory Water Grade Three Standard GB6682-2008 and ASTM CAP NCCLS.
• Water Production Rate: ≥ 150 L/h
• Water Intake Rate: 2.5-3 L/min
• Delivery Pressure: 0.1-0.4 Mpa
• pH: 5.0-8.0
• Oxidizable Substances (As O): ≤ 0.4 mg/L
• Total hardness less the 0.4mg/L
• Total Organic Carbon (TOC): < 500 ppb
• Evaporation Residue: ≤ 2.0 mg/L

Equipment Configuration and Advantages:

1. MOLIC Micro-Computer Control:
• Equipped with a patented control system for precise and efficient operation.
2. Built-in RO Membrane Antiscale:
• Includes automatic timed flush procedures to prevent scaling and a manual RO membrane cleaning button for easy maintenance.
3. Water Conductivity On-line Monitoring:
• Enables real-time monitoring and control, facilitating man-machine interaction for optimal water quality management.
4. Moldistributor System:
• Features a patented transport system for efficient distribution and water flow management.
5. 300L PE Reverse Osmosis Water Tank:
• Provides storage to ensure a continuous supply of high-quality pure water.

Flow schematic    Tap water→ 1st stage 5μmPP filter→ 2nd stage activated carbon filter→ 3rd stage 1μmPP filter→ 1st booster pump →1st Reverse osmosis membrane→2nd booster pump →2nd Reverse osmosis membrane→ 300L PE Pure water tank→ delivery pump - Pure water outlet

Scope of Application:

• Designed to meet the requirements of general chemical analysis, experimental apparatus cleaning, conventional water for testing centers, and pure water for high-pressure sterilization pot use.

Technical Features:

• The system primarily consists of the pretreatment system, RO system, pure water system conveying unit, and control system.
• Automatic control over the entire process, including:
• Auto water production.
• Auto-stop when the water tank is full.

System Components and Functions:

1. Pretreatment Filters:
• Designed to filter out impurities in raw water, such as tiny particles, suspended solids, and colloids.
• Reduces inlet water turbidity and prevents fouling of the RO membrane, ensuring longer membrane life and optimal performance.
2. RO Membrane:
• Utilizes a high-quality, US-imported RO membrane.
• Effectively removes salt ions, organics, bacteria, and viruses from water.
• Achieves a desalination and sterilization rate of 98%, ensuring high-purity water output.
3. Pure Water Pump:
• Equipped with a specialized transfer pump for fast intake of ultrapure water.
• Delivers water at a rate of 2.5-3 liters per minute, ensuring efficient and rapid water supply for various applications.

Filter Name and Recommended Replacement Time:
